The Influence of Magnetostrictions on Vibrations on One Phase Transformer: Unveiling the Mystery

Introduction

Vibrations in transformers are a common phenomenon that can have significant consequences on the performance and lifespan of these critical electrical devices. One of the primary causes of these vibrations is the effect of magnetostrictions, which refers to the changes in material dimensions due to the influence of magnetic fields. In this thesis, we aim to investigate the influence of magnetostrictions on vibrations in one phase transformers. Our study was conducted by measuring vibrations on the transformer under various conditions, including without load and with loads, with variations in magnetic flux.

Understanding Magnetostrictions and Vibrations

Magnetostrictions are a fundamental property of magnetic materials, where the dimensions of the material change in response to the magnetic field. This phenomenon is a result of the interaction between the magnetic field and the material's internal structure. In the context of transformers, magnetostrictions can lead to vibrations, which can be detrimental to the device's performance and lifespan. The vibrations can be caused by the expansion and contraction of the transformer's core and windings due to the changing magnetic field.

Research and Analysis Methods

Our study employed a magnetic flux variation method to measure the effect of magnetostrictions on vibrations in one phase transformers. We utilized the Arduino Uno and the ADXL 345 accelerometer sensor to measure the resulting vibration. The data was then analyzed using the Matlab Vibration Data Toolbox application. This analysis included the measurement of the magnitude spectrum of frequency amplitude, root mean square (RMS) vibration, and maximum deviation and minimum vibration.

Experimental Setup and Procedure

The experimental setup consisted of a one phase transformer, an Arduino Uno, and an ADXL 345 accelerometer sensor. The transformer was subjected to various conditions, including without load and with loads, with variations in magnetic flux. The magnetic flux was controlled using a variable transformer. The Arduino Uno was programmed to measure the vibration data using the ADXL 345 accelerometer sensor. The data was then transmitted to the Matlab Vibration Data Toolbox application for analysis.

Results and Discussion

The results of our study showed that the vibrations in the transformer one phase without a load reached its peak when the magnetic flux reached 1.4 Tesla. In this condition, the magnitude of frequency amplitude, vibration RMS, maximum deviation distance, and minimum vibration reached the highest value. However, the results also showed an interesting phenomenon when the transformer was given a burden. There was a significant decrease in the magnitude of frequency amplitude, vibration RMS, maximum deviation distance, and minimum vibration, especially at small loads. This decrease shows that saturation in the core of the transformer has an important role in determining the level of vibration produced.

Conclusion and Implications

Our study succeeded in revealing the significant effect of magnetostrictions on vibrations in one phase transformers. These results indicate that magnetic flux and transformer core saturation are the main factors that affect vibrations. This finding provides a better understanding of the vibration mechanism of the transformer and opens opportunities for the development of a more optimal and minimal transformer design.

Practical Benefits and Implications

This study provides significant practical benefits for the transformer industry. Understanding the effect of magnetostrictions on vibration allows engineers to design a more durable and long-lived transformer. This knowledge also helps in predicting and minimizing the potential for damage due to excessive vibration. In addition, the results of this study open opportunities for further research related to the optimization of transformer design to achieve better efficiency and durability.

Future Research Directions

Our study provides a foundation for further research in the field of transformer design and optimization. Future studies can focus on developing more advanced models to predict the vibration behavior of transformers under various conditions. Additionally, research can be conducted to explore the effects of other factors, such as temperature and humidity, on the vibration behavior of transformers.

Conclusion

In conclusion, our study has demonstrated the significant effect of magnetostrictions on vibrations in one phase transformers. The results of this study provide valuable insights into the vibration mechanism of transformers and open opportunities for the development of more optimal and minimal transformer designs. We hope that this study will contribute to the advancement of knowledge in the field of electrical engineering and inspire further research in this area.

Recommendations

Based on the findings of this study, we recommend that engineers and researchers in the field of electrical engineering take into account the effects of magnetostrictions on vibrations when designing and optimizing transformers. Additionally, we recommend that further research be conducted to explore the effects of other factors, such as temperature and humidity, on the vibration behavior of transformers.

Limitations and Future Work

Our study has several limitations, including the use of a single type of transformer and the limited range of magnetic flux values tested. Future studies can focus on exploring the effects of other types of transformers and a wider range of magnetic flux values. Additionally, research can be conducted to explore the effects of other factors, such as temperature and humidity, on the vibration behavior of transformers.
