Introduction

Electric motors are crucial tools in various industries, converting electrical energy into mechanical energy. When selecting the right motor, it is essential to consider its characteristics to ensure efficient and economical operation. One type of motor commonly used is the direct current (DC) motor with shunt reinforcement. However, when operating under loaded conditions, the phenomenon of anchor reaction can reduce the initial flux, affecting the motor's mechanical characteristics.

The Anchor Reaction and Its Impact

The anchor reaction is a phenomenon that occurs when the current flowing through the anchor of the motor creates a magnetic flux opposite to the flux produced by the winding. This can lead to a decrease in motor performance, particularly in terms of rotation and torque characteristics. By reducing magnetic flux, the anchor reaction causes the motor to work less efficiently, resulting in reduced torque and rotating speed.

The Effects of Anchor Reaction on Motor Performance

The anchor reaction can have a significant impact on motor performance, leading to:

Reduced torque output
Decreased rotating speed
Increased energy consumption
Decreased motor efficiency

Approaches to Overcome the Anchor Reaction

To overcome the problems caused by the anchor reaction, three main approaches can be applied:

1. Continuous Brush Shift

This method involves continuously shifting the brushes to maintain optimal contact with the commutator. However, this approach is not feasible in this context due to the complexity and maintenance requirements.

2. The Use of Auxiliary Pole (Interpole)

The auxiliary pole, also known as the interpole, is a method that can be used to increase magnetic flux and compensate for the reduction in flux due to the anchor reaction. By applying the auxiliary poles, the motor can maintain operational efficiency, even in a loaded condition.

3. Compensation Belitan

This method involves using a compensation winding to counteract the effects of the anchor reaction. However, the focus of this analysis is on the use of auxiliary poles.

The Effect of Auxiliary Pole on the Characteristics of the Load Torque

The use of auxiliary poles has a significant positive impact on the characteristics of the torque of the load of the motor current in the direction of the shunt reinforcement. With the presence of auxiliary poles, the additional flux produced helps increase motor torque while working in a loaded condition. This means that the motor can maintain a more stable rotation speed even though the load received increases.

Analyzing the Torque Curve

The characteristics of the rotation can be further analyzed by mapping the torque curve to the rotational speed. This curve generally shows non-linear relationships, where torque increases at low speeds but will decrease at high speed due to an increase in anchor reaction. With the application of auxiliary poles, the area where the motor operates efficiently can be expanded, thus providing greater flexibility in practical applications.

Conclusion

In this analysis, it can be concluded that the characteristics of the rotation of the motor current in the direction of the shunt reinforcement can be improved significantly using the auxiliary pole. This approach not only overcomes the problem of anchor reactions but also increases motor performance in applications that require high torque and stable rotating speed. By understanding these characteristics, engineers and practitioners in the field of electrical energy conversion can make more appropriate decisions in the selection and use of electric motors.

Recommendations for Future Research

Based on the findings of this analysis, the following recommendations for future research are proposed:

Investigate the effects of different auxiliary pole configurations on motor performance
Analyze the impact of anchor reaction on motor efficiency in various operating conditions
Develop a mathematical model to predict motor performance under different operating conditions

By conducting further research in this area, engineers and practitioners can gain a deeper understanding of the characteristics of the rotation of the motor current in the direction of the shunt reinforcement and develop more efficient and effective solutions for various applications.
