Sonos4: Revolutionizing Radio Broadcasting with Advanced Software

Introduction

In the world of radio broadcasting, having the right equipment is crucial for producing high-quality audio that captivates listeners. Sonos4 is a cutting-edge software solution that enables radio broadcasters to turn their Windows PC into a state-of-the-art broadcast processor. With its advanced features and user-friendly interface, Sonos4 is an ideal solution for AM, FM, DAB, and internet streaming broadcasting.

Central Feature: Software Multiband Compressor Limiter (MBL9)

The heart of Sonos4 is its software multiband compressor limiter (MBL9), a sophisticated processor that achieves its punch through the use of a unique distortion-masked final clipper. This innovative technology allows Sonos4 to produce loud and clear audio, making it an ideal solution for radio broadcasting. The MBL9 processor is designed to work seamlessly with a suitable sound card, using either ASIO or the Windows native multimedia sound interface.

Interfaces and Compatibility

Sonos4 interfaces with sound cards using either ASIO or the Windows native multimedia sound interface. If the ASIO interface is used, low latency mode can be enabled, allowing for off-air monitoring while speaking, just like hardware FM and AM processors. However, the use of ASIO is dependent on the sound card having ASIO drivers, which most 'Pro' sound cards support.

Multiple Instances and Processor Architecture

Sonos4 supports multiple instances, making it theoretically possible to have up to eight processors. However, current quad-core CPUs can only support two instances of the MBL9 processor. The processor architecture is similar in each of the five processors, including:

Single dual or tri-band gated AGC
Gated multiband limiter (optional)
Single-band gated limiting
Pre-emphasis for FM (switchable)
Three stages of parametric equalization
Stereo widener
Stereo enhancer
Phase rotator
Filtering for FM and AM

Adjustable Processor Settings and Preset Files

The processor settings in Sonos4 are fully adjustable, with easy-to-use saving and loading of preset files. This feature allows broadcasters to quickly switch between different formats and settings, making it an ideal solution for radio stations with multiple formats.

Daypart Scheduler and Fail Over Feature

Sonos4 also features a 'Daypart' scheduler, which enables changes of preset (format) by time of day and day of the week. This feature is particularly useful for radio stations that need to switch between different formats during different times of the day. Additionally, the 'Fail Over' or failsafe feature switches the input to a backup should the main source fail, ensuring that the broadcast continues uninterrupted.

Driving FM Transmitter MPX Inputs

Sonos4 can drive FM transmitter MPX inputs directly, but it requires a 192kHz sound card with adequate bandwidth to pass the MPX signal. The stereo multiplex encoder has adjustable clipping for extra loudness, and the pilot tone amplitude is also adjustable.

RDS/RBDS Encoder and SCA Generator

The RDS/RBDS encoder in Sonos4 supports all the basic RDS features, plus it has a scrolling 'Program Service Name' feature with multiple messages that can be set up as a rotation. The SCA generator supports frequencies from 20kHz to 90kHz and deviation from 1kHz to 10kHz.

Conclusion

Sonos4 is a powerful software solution that enables radio broadcasters to produce high-quality audio with ease. Its advanced features, including the software multiband compressor limiter (MBL9), adjustable processor settings, and Daypart scheduler, make it an ideal solution for AM, FM, DAB, and internet streaming broadcasting. With its user-friendly interface and compatibility with a wide range of sound cards, Sonos4 is a must-have for any radio broadcaster looking to take their audio to the next level.

Technical Specifications

Software multiband compressor limiter (MBL9)
Adjustable processor settings
Daypart scheduler
Fail Over or failsafe feature
RDS/RBDS encoder
SCA generator
Compatible with ASIO and Windows native multimedia sound interface
Supports multiple instances
Compatible with 192kHz sound cards

System Requirements

Windows PC
Suitable sound card
ASIO drivers (for ASIO interface)
Quad-core CPU (for multiple instances)

Conclusion

Q: What is Sonos4 and what does it do?

A: Sonos4 is a software solution that enables radio broadcasters to turn their Windows PC into a state-of-the-art broadcast processor. It uses a software multiband compressor limiter (MBL9) to produce high-quality audio for AM, FM, DAB, and internet streaming broadcasting.

Q: What are the key features of Sonos4?

A: The key features of Sonos4 include:

Software multiband compressor limiter (MBL9)
Adjustable processor settings
Daypart scheduler
Fail Over or failsafe feature
RDS/RBDS encoder
SCA generator
Compatible with ASIO and Windows native multimedia sound interface
Supports multiple instances
Compatible with 192kHz sound cards

Q: What kind of sound card do I need to use with Sonos4?

A: Sonos4 requires a suitable sound card that supports ASIO or the Windows native multimedia sound interface. Most 'Pro' sound cards support ASIO, but you should check with your sound card manufacturer to confirm compatibility.

Q: Can I use Sonos4 with a quad-core CPU?

A: Yes, Sonos4 can be used with a quad-core CPU, but it may only support two instances of the MBL9 processor due to CPU limitations.

Q: How do I adjust the processor settings in Sonos4?

A: The processor settings in Sonos4 are fully adjustable, with easy-to-use saving and loading of preset files. This feature allows broadcasters to quickly switch between different formats and settings.

Q: What is the Daypart scheduler and how does it work?

A: The Daypart scheduler is a feature in Sonos4 that enables changes of preset (format) by time of day and day of the week. This feature is particularly useful for radio stations that need to switch between different formats during different times of the day.

Q: What is the Fail Over or failsafe feature and how does it work?

A: The Fail Over or failsafe feature in Sonos4 switches the input to a backup should the main source fail, ensuring that the broadcast continues uninterrupted.

Q: Can I drive FM transmitter MPX inputs directly from Sonos4?

A: Yes, Sonos4 can drive FM transmitter MPX inputs directly, but it requires a 192kHz sound card with adequate bandwidth to pass the MPX signal.

Q: What are the RDS/RBDS encoder and SCA generator features in Sonos4?

A: The RDS/RBDS encoder in Sonos4 supports all the basic RDS features, plus it has a scrolling 'Program Service Name' feature with multiple messages that can be set up as a rotation. The SCA generator supports frequencies from 20kHz to 90kHz and deviation from 1kHz to 10kHz.

Q: Is Sonos4 compatible with multiple sound cards?

A: Yes, Sonos4 is compatible with multiple sound cards, including those that support ASIO and the Windows native multimedia sound interface.

Q: Can I use Sonos4 with a Mac or Linux computer?

A: No, Sonos4 is only compatible with Windows PCs.

Q: What kind of support does Sonos4 offer?

A: Sonos4 offers comprehensive support, including online documentation, user forums, and technical support.

Q: How do I get started with Sonos4?

A: To get started with Sonos4, simply download and install the software, and follow the on-screen instructions to configure your sound card and processor settings.

Q: Is Sonos4 a one-time purchase or a subscription-based service?

A: Sonos4 is a one-time purchase, with no subscription fees or ongoing costs.

Q: Can I try Sonos4 before buying it?

A: Yes, Sonos4 offers a free trial version that allows you to try out the software before purchasing it.
