Improvement of existing drainage channel dimensions

Oct 13, 2025 by thesweetdesigns.com 61 views

Review the Drainage System to Overcome Inundation Floods in Villa Johor Housing, Kec. Medan Johor

Introduction

Villa Johor Housing, located in the Medan Johor District, has been experiencing severe problems with inundation floods for over a decade. Despite its relatively small area of 7,836 m², the housing complex has been plagued by frequent flooding, with puddles reaching heights of 40-100 cm and low tide lasting up to 6 hours. This situation has raised concerns about the existing drainage system and its ability to handle the area's rainfall. In this study, we aim to review the drainage system and provide recommendations to overcome the problem of inundation floods in Villa Johor Housing.

Background

Villa Johor Housing has been established for 10 years, but despite its age, the problem of floods has persisted. The area's rainfall is a significant concern, with data from the Polonia Station over the past 20 years showing a high frequency of extreme rainfall events. To better understand the rainfall pattern, we analyzed the data using four frequency distribution methods: normal distribution, log-normal distribution, Pearson II log distribution, and Gumbel distribution. Our analysis revealed that the Gumbel distribution provides the most extreme results, indicating a high likelihood of extreme rainfall events in the area.

Methodology

To estimate the water discharge that might occur in the area, we considered the re-period of rainfall for 2 years and 5 years. We used the results of the analysis to calculate the plan discharge, which includes the dirty water discharge and cumulative discharge. This data was then processed for hydraulic analysis to determine the optimal drainage channel dimensions. Our calculation results showed a significant difference between the calculated channel dimensions and the existing dimensions, indicating a need for improvement.

Results

Based on our analysis, we recommend the construction of infiltration wells for each housing unit according to the type of building. The capacity of these infiltration wells varies, with a 100/160 house type accommodating 69 liters, type 48/90 holding 14 liters, and type 64/105 accommodating 16 liters. We believe that this solution can be an effective way to reduce the impact of adverse flooding in the area.

Discussion

The problem of flooding in Villa Johor Housing is not only a concern for the residents but also a part of a greater effort in the management of water resources and flood disaster mitigation in urban areas. With a better understanding of the pattern of rainfall and an efficient drainage system, it is hoped that similar events can be minimized in the future. Our study provides a systematic and data-based approach to addressing the problem of flooding in the area, and we believe that it can serve as a model for other urban areas facing similar challenges.

Conclusion

In conclusion, our study has shown that the existing drainage system in Villa Johor Housing is inadequate to handle the area's rainfall. We recommend the construction of infiltration wells for each housing unit according to the type of building, which can be an effective solution to reduce the impact of adverse flooding. We hope that our study will serve as a catalyst for the housing management or local government to take the necessary actions to overcome the problem of flooding in the area, creating a safer and more comfortable environment for housing residents.

Recommendations

Based on our study, we recommend the following:

Improvement of existing drainage channel dimensions: The calculated channel dimensions show a significant difference from the existing dimensions, indicating a need for improvement.
Construction of infiltration wells: The construction of infiltration wells for each housing unit according to the type of building can be an effective solution to reduce the impact of adverse flooding.
Regular maintenance of drainage system: Regular maintenance of the drainage system is essential to ensure its optimal functioning and prevent clogging.
Public education and awareness: Public education and awareness about the importance of proper waste disposal and the consequences of flooding can help prevent the problem of flooding in the area.

Future Research Directions

Our study has highlighted the need for further research in the area of flood disaster mitigation in urban areas. Some potential future research directions include:

Development of a more accurate rainfall prediction model: A more accurate rainfall prediction model can help predict extreme rainfall events and provide early warnings for flooding.
Investigation of the impact of climate change on flooding: Climate change is expected to increase the frequency and severity of extreme weather events, including flooding. Investigating the impact of climate change on flooding can help inform strategies for flood disaster mitigation.
Development of a more efficient drainage system: Developing a more efficient drainage system can help reduce the impact of flooding in urban areas.

Limitations of the Study

Our study has several limitations, including:

Limited data availability: The availability of rainfall data from the Polonia Station over the past 20 years was limited, which may have affected the accuracy of our analysis.
Simplification of the drainage system: Our study assumed a simplified drainage system, which may not accurately reflect the complexity of the actual drainage system.
Lack of consideration of other factors: Our study did not consider other factors that may contribute to flooding, such as land use changes and urbanization.

Conclusion

Q: What is the main problem with the drainage system in Villa Johor Housing?

A: The main problem with the drainage system in Villa Johor Housing is that it is inadequate to handle the area's rainfall, leading to frequent flooding and puddles reaching heights of 40-100 cm.

Q: What is the cause of the flooding in Villa Johor Housing?

A: The cause of the flooding in Villa Johor Housing is the inadequate drainage system, which is unable to handle the area's rainfall. Other factors such as land use changes and urbanization may also contribute to the problem.

Q: What is the recommended solution to overcome the problem of flooding in Villa Johor Housing?

A: The recommended solution to overcome the problem of flooding in Villa Johor Housing is the construction of infiltration wells for each housing unit according to the type of building. This can be an effective way to reduce the impact of adverse flooding.

Q: How do infiltration wells work?

A: Infiltration wells are designed to allow rainwater to infiltrate into the ground, reducing the amount of water that flows into the drainage system. They are typically installed in each housing unit and are designed to accommodate the type of building.

Q: What are the benefits of infiltration wells?

A: The benefits of infiltration wells include reducing the impact of adverse flooding, reducing the amount of stormwater that enters the drainage system, and improving the overall water quality.

Q: How can the public help to prevent flooding in Villa Johor Housing?

A: The public can help to prevent flooding in Villa Johor Housing by properly disposing of waste, not littering, and reporting any issues with the drainage system to the authorities.

Q: What is the role of the local government in addressing the problem of flooding in Villa Johor Housing?

A: The local government has a crucial role to play in addressing the problem of flooding in Villa Johor Housing. They can provide funding for the construction of infiltration wells, improve the drainage system, and provide education and awareness programs to the public.

Q: What is the timeline for implementing the recommended solution?

A: The timeline for implementing the recommended solution will depend on various factors, including funding, technical feasibility, and community engagement. However, it is expected that the construction of infiltration wells will begin within the next 6-12 months.

Q: How will the effectiveness of the recommended solution be monitored?

A: The effectiveness of the recommended solution will be monitored through regular inspections, water quality monitoring, and community feedback. This will help to identify any issues and make necessary adjustments to the solution.

Q: What are the potential risks and challenges associated with the recommended solution?

A: The potential risks and challenges associated with the recommended solution include the high cost of construction, potential technical issues, and community resistance to change. However, these risks can be mitigated through careful planning, community engagement, and regular monitoring.

Q: How can the public get involved in the implementation of the recommended solution?

A: The public can get involved in the implementation of the recommended solution by attending community meetings, providing feedback, and participating in education and awareness programs. They can also volunteer to help with the construction of infiltration wells and other related activities.

Q: What is the expected outcome of the recommended solution?

A: The expected outcome of the recommended solution is a significant reduction in the impact of adverse flooding in Villa Johor Housing, improved water quality, and a safer and more comfortable environment for housing residents.
